riaz@boombox:~ $ uname -a
Linux boombox 6.12.62+rpt-rpi-v8 #1 SMP PREEMPT Debian 1:6.12.62-1+rpt1 (2025-12-18) aarch64 GNU/Linux

riaz@boombox:~ $ i2cdetect -y 1
     0  1  2  3  4  5  6  7  8  9  a  b  c  d  e  f
00:                         -- -- -- -- -- -- -- --
10: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
20: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
30: -- -- -- -- -- -- -- -- -- -- -- -- 3c -- -- --
40: -- -- -- -- -- -- -- -- -- -- -- -- UU -- -- --
50: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
60: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
70: -- -- -- -- -- -- -- --

# make venv
python3 -m venv ~/luma-env

# install lib
~/luma-env/bin/python -m pip install --upgrade luma.oled

# install dependencies
sudo apt-get update

# this didn't work, the libs are outdated
#sudo apt-get install python3 python3-pip python3-pil libjpeg-dev zlib1g-dev libfreetype6-dev liblcms2-dev libopenjp2-7 libtiff5 -y

# this did work
sudo apt-get install python3 python3-pip python3-pil libjpeg-dev zlib1g-dev libfreetype-dev liblcms2-dev libopenjp2-7 libtiff6 -y

sudo usermod -a -G spi,gpio,i2c pi

sudo apt install git
git clone https://github.com/rm-hull/luma.examples.git
cd luma.examples/examples

~/luma-env/bin/python 3d_box.py

cp sys_info_extended.py oled.py

~/luma-env/bin/python -m pip install --upgrade luma.oled

/home/riaz/luma-env/bin/python /home/riaz/luma.examples/examples/oled.py

sudo systemctl start oled.service

sudo systemctl enable oled.service

#!/usr/bin/env python
# -*- coding: utf-8 -*-
# Adapted from 2023 Richard Hull and contributors
# See https://github.com/rm-hull/luma.examples


import time
import sqlite3
from pathlib import Path
from datetime import datetime
from demo_opts import get_device
from luma.core.render import canvas
from PIL import ImageFont
import psutil
import subprocess as sp
import socket
from collections import OrderedDict


def get_temp():
    temp = float(sp.getoutput("vcgencmd measure_temp").split("=")[1].split("'")[0])
    return temp


def get_cpu():
    return psutil.cpu_percent()


def get_mem():
    return psutil.virtual_memory().percent


def get_disk_usage():
    usage = psutil.disk_usage("/")
    return usage.used / usage.total * 100


def get_uptime():
    uptime = ("%s" % (datetime.now() - datetime.fromtimestamp(psutil.boot_time()))).split(".")[0]
    return "UpTime: %s" % (uptime)


def find_single_ipv4_address(addrs):
    for addr in addrs:
        if addr.family == socket.AddressFamily.AF_INET:  # IPv4
            return addr.address


def get_ipv4_address(interface_name=None):
    if_addrs = psutil.net_if_addrs()
    if_stats = psutil.net_if_stats()

    if isinstance(interface_name, str) and interface_name in if_addrs:
        addrs = if_addrs.get(interface_name)
        address = find_single_ipv4_address(addrs)
        return address if isinstance(address, str) else ""
    else:
        # filter out loopback interfaces based on their address
        if_addrs_filtered = {
            iface: addrs
            for iface, addrs in if_addrs.items()
            if not any(addr.address == '127.0.0.1' for addr in addrs if addr.family == socket.AF_INET)
        }

        if_names_sorted = [
            iface for iface, _ in sorted(if_stats.items(), key=lambda x: (x[1].isup, x[1].duplex), reverse=True)
            if iface in if_addrs_filtered
        ]

        if_addrs_sorted = OrderedDict((iface, if_addrs_filtered[iface]) for iface in if_names_sorted)

        for _, addrs in if_addrs_sorted.items():
            address = find_single_ipv4_address(addrs)
            if isinstance(address, str):
                return address

        return ""


def get_ip(network_interface_name):
    return "IP: %s" % (get_ipv4_address(network_interface_name))


def format_percent(percent):
    return "%5.1f" % (percent)


def draw_text(draw, margin_x, line_num, text):
    draw.text((margin_x, margin_y_line[line_num]), text, font=font_default, fill="white")


def draw_bar(draw, line_num, percent):
    top_left_y = margin_y_line[line_num] + bar_margin_top
    draw.rectangle((margin_x_bar, top_left_y, margin_x_bar + bar_width, top_left_y + bar_height), outline="white")
    draw.rectangle((margin_x_bar, top_left_y, margin_x_bar + bar_width * percent / 100, top_left_y + bar_height), fill="white")


def draw_bar_full(draw, line_num):
    top_left_y = margin_y_line[line_num] + bar_margin_top
    draw.rectangle((margin_x_bar, top_left_y, margin_x_bar + bar_width_full, top_left_y + bar_height), fill="white")
    draw.text((65, top_left_y - 2), "100 %", font=font_full, fill="black")


MOODE_DB = "/var/local/www/db/moode-sqlite3.db"
SPOTMETA_FILE = "/var/local/www/spotmeta.txt"
APLMETA_FILE = "/var/local/www/aplmeta.txt"

RENDERER_PARAMS = {
    "spotactive": ("Spotify", SPOTMETA_FILE),
    "aplactive": ("AirPlay", APLMETA_FILE),
    "btactive": ("Bluetooth", None),
    "slactive": ("Squeezelite", None),
    "rbactive": ("Roon", None),
    "inpactive": ("Analog In", None),
}


def get_active_renderer():
    """Query moOde DB for active renderer. Returns (name, meta_file) or None."""
    try:
        conn = sqlite3.connect(MOODE_DB)
        params = list(RENDERER_PARAMS.keys())
        placeholders = ",".join("?" for _ in params)
        cursor = conn.execute(
            "SELECT param, value FROM cfg_system WHERE param IN (%s)" % placeholders,
            params
        )
        for param, value in cursor:
            if str(value) == "1":
                conn.close()
                return RENDERER_PARAMS[param]
        conn.close()
    except Exception:
        pass
    return None


def parse_renderer_meta(filepath):
    """Parse a moOde ~~~-delimited metadata file. Returns dict or None."""
    try:
        content = Path(filepath).read_text().strip()
        if not content:
            return None
        parts = content.split("~~~")
        if len(parts) >= 3:
            return {
                "title": parts[0],
                "artist": parts[1],
                "album": parts[2],
                "format": parts[5] if len(parts) > 5 else "",
            }
    except Exception:
        pass
    return None


def get_mpd_playing():
    """Check if MPD is actively playing. Returns dict or None."""
    try:
        import json
        import urllib.request
        resp = urllib.request.urlopen("http://localhost/engine-mpd.php", timeout=3)
        data = json.loads(resp.read())
        if data.get("state") == "play":
            return {
                "title": data.get("title", "Unknown"),
                "artist": data.get("artist", "Unknown"),
                "album": data.get("album", ""),
                "format": data.get("encoded", ""),
            }
    except Exception:
        pass
    return None


SCROLL_SPEED = 2       # Pixels per frame
SCROLL_PAUSE = 3       # Frames to pause at start and end
SCROLL_GAP = 20        # Pixels of gap before text repeats

# Scroll state: tracks offset and pause counter per field, resets on song change
_scroll_state = {"artist": "", "title": "", "artist_off": 0, "title_off": 0,
                 "artist_pause": SCROLL_PAUSE, "title_pause": SCROLL_PAUSE}


def _scroll_x(text, text_w, width, field):
    """Calculate x position for text, advancing scroll state if needed."""
    if text_w <= width:
        # Fits on screen - center it, reset scroll
        _scroll_state[field + "_off"] = 0
        _scroll_state[field + "_pause"] = SCROLL_PAUSE
        return (width - text_w) // 2

    # Text is wider than screen - scroll it
    off = _scroll_state[field + "_off"]
    pause = _scroll_state[field + "_pause"]
    max_off = text_w - width + SCROLL_GAP

    if off == 0 and pause > 0:
        # Pause at start
        _scroll_state[field + "_pause"] = pause - 1
        return 0
    elif off >= max_off:
        # Reached the end - reset with pause
        _scroll_state[field + "_off"] = 0
        _scroll_state[field + "_pause"] = SCROLL_PAUSE
        return 0
    else:
        # Scroll left
        _scroll_state[field + "_off"] = off + SCROLL_SPEED
        return -off


def draw_now_playing(device, source, info):
    """Draw now-playing screen with song details."""
    # Reset scroll state when song changes
    if info["artist"] != _scroll_state["artist"] or info["title"] != _scroll_state["title"]:
        _scroll_state["artist"] = info["artist"]
        _scroll_state["title"] = info["title"]
        _scroll_state["artist_off"] = 0
        _scroll_state["title_off"] = 0
        _scroll_state["artist_pause"] = SCROLL_PAUSE
        _scroll_state["title_pause"] = SCROLL_PAUSE

    with canvas(device) as draw:
        w = device.width

        # Source label at top left
        draw.text((0, 0), source, font=font_full, fill="white")

        # Artist - scrolls if too wide
        artist = info["artist"].replace("\n", " ")
        artist_w = draw.textlength(artist, font=font_default)
        ax = _scroll_x(artist, artist_w, w, "artist")
        draw.text((ax, 14), artist, font=font_default, fill="white")

        # Title - scrolls if too wide
        title = info["title"].replace("\n", " ")
        title_w = draw.textlength(title, font=font_default)
        tx = _scroll_x(title, title_w, w, "title")
        draw.text((tx, 28), title, font=font_default, fill="white")

        # Format info - centered at bottom
        fmt = info.get("format", "")
        if fmt:
            fmt_w = draw.textlength(fmt, font=font_full)
            fx = max(0, (w - fmt_w) // 2)
            draw.text((fx, 44), fmt, font=font_full, fill="white")


def draw_renderer_only(device, source):
    """Draw screen showing only the active renderer name (e.g. Bluetooth)."""
    with canvas(device) as draw:
        label = "Playing via"
        label_w = draw.textlength(label, font=font_full)
        draw.text((max(0, (device.width - label_w) // 2), 16), label, font=font_full, fill="white")
        source_w = draw.textlength(source, font=font_default)
        draw.text((max(0, (device.width - source_w) // 2), 32), source, font=font_default, fill="white")


def stats(device):
    with canvas(device) as draw:
        temp = get_temp()
        draw_text(draw, 0, 0, "Temp")
        draw_text(draw, margin_x_figure, 0, "%s'C" % (format_percent(temp)))

        cpu = get_cpu()
        draw_text(draw, 0, 1, "CPU")
        if cpu < 100:
            draw_text(draw, margin_x_figure, 1, "%s %%" % (format_percent(cpu)))
            draw_bar(draw, 1, cpu)
        else:
            draw_bar_full(draw, 1)

        mem = get_mem()
        draw_text(draw, 0, 2, "Mem")
        if mem < 100:
            draw_text(draw, margin_x_figure, 2, "%s %%" % (format_percent(mem)))
            draw_bar(draw, 2, mem)
        else:
            draw_bar_full(draw, 2)

        disk = get_disk_usage()
        draw_text(draw, 0, 3, "Disk")
        if disk < 100:
            draw_text(draw, margin_x_figure, 3, "%s %%" % (format_percent(disk)))
            draw_bar(draw, 3, disk)
        else:
            draw_bar_full(draw, 3)

        if datetime.now().second % (toggle_interval_seconds * 2) < toggle_interval_seconds:
            draw_text(draw, 0, 4, get_uptime())
        else:
            draw_text(draw, 0, 4, get_ip(network_interface_name))


font_size = 12
font_size_full = 10
margin_y_line = [0, 13, 25, 38, 51]
margin_x_figure = 78
margin_x_bar = 31
bar_width = 52
bar_width_full = 95
bar_height = 8
bar_margin_top = 3
toggle_interval_seconds = 4


# None : find suitable IPv4 address among all network interfaces
# or specify the desired interface name as string.
network_interface_name = None


device = get_device()
font_default = ImageFont.truetype(str(Path(__file__).resolve().parent.joinpath("fonts", "DejaVuSansMono.ttf")), font_size)
font_full = ImageFont.truetype(str(Path(__file__).resolve().parent.joinpath("fonts", "DejaVuSansMono.ttf")), font_size_full)


FETCH_INTERVAL = 8     # Re-fetch metadata every N frames (~2 sec at 0.25s/frame)
_frame = 0
_cached_display = None  # ("now_playing", source, info) or ("renderer", source) or ("stats",)

while True:
    # Re-fetch source and metadata periodically, not every frame
    if _frame % FETCH_INTERVAL == 0:
        renderer = get_active_renderer()
        if renderer is not None:
            source_name, meta_file = renderer
            if meta_file is not None:
                info = parse_renderer_meta(meta_file)
                if info:
                    _cached_display = ("now_playing", source_name, info)
                else:
                    _cached_display = ("renderer", source_name)
            else:
                _cached_display = ("renderer", source_name)
        else:
            mpd_info = get_mpd_playing()
            if mpd_info:
                _cached_display = ("now_playing", "moOde", mpd_info)
            else:
                _cached_display = ("stats",)

    # Draw the current display
    if _cached_display[0] == "now_playing":
        draw_now_playing(device, _cached_display[1], _cached_display[2])
        time.sleep(0.25)
    elif _cached_display[0] == "renderer":
        draw_renderer_only(device, _cached_display[1])
        time.sleep(1)
    else:
        stats(device)
        time.sleep(1)

    _frame += 1
